Cantilever Bar Rack - Modular Steel Racking

Product Information

Our Cantilever Bar Racking System is engineered for efficient storage of long, bulky, or awkward materials in warehouses, factories, and workshops. Supplied as Starter or Add-On Units, this modular system offers strength, stability, and customisability.

✅ Load Capacity - Up to 2200kg per side
✅ Modular Setup - Starter & Extension Bays for flexible layouts
✅ Frame - Galvanized steel with blue powder-coated support arms
✅ Adjustable Arms - 75mm spacing with 2? rake
✅ End Stops - Optional safety feature, bolted in two positions
✅ Bay Spacing - Choose 1000mm or 1500mm for best fit
✅ Side Configurations - Single-sided (3 arms) or double-sided (6 arms)
✅ Fast Delivery - 5 working days
✅ Warranty - 5-year guarantee

Bays Include:

• Starter Bay - 2 upright frames, 3 beam levels, bracing & fittings
• Extension Bay - 1 upright frame, 3 beam levels, bracing & fittings

Ordering Note: All dimensions are nominal shelf sizes. For custom heights (2432mm or 2964mm), contact our team. Made to order and non-returnable unless damaged or faulty.

Arm Length	Max Load per side at 1976mm high
600mm	2200kg
800mm	1900kg
1000mm	1600g
